A Y-connector pack is used in Percutaneous Transluminal Coronary Angioplasty(PTCA); A channel outside the body would be built for the guide wire with the help of this pack.
Large lumen: 9Fr,3.0mm for various device compatibility
One-hand operation with various types: Rotating, push-click, push-pull, push-rotate.
No leakage under 80 Kpa
Accessories available: Extension Tube with stopcock, insertion tool, torque device.
| Ref. NO | Product Description | Type |
| YCK111 | Y-Connector (1), Insertion Tool (l), Torque Device (1) | Screw |
| YCK111A | Y-Connector (1), Insertion Tool (1), Torque Device (1),Extension tube with stopcock(1) | |
| YCK119B | Y-Connector (1), Insertion Tool (1), Torque Device (1) | Push-Click |
| YCK119A | Y-Connector (1), Insertion Tool (1), Torque Device (1),Extension tube with stopcock (1) | |
| YCK118B | Y-Connector (1), Insertion Tool (1), Torque Device (1) | Push-Pull |
| YCK118A | Y-Connector (1), Insertion Tool (1), Torque Device (1),Extension tube with stopcock (1) | |
| YCK100C | Y-Connector (1), Insertion Tool (1), Torque Device (1) | Push-Rotate |
| YCK100F | Y-Connector (1), Insertion Tool (1), Torque Device (1),Extension tube with stopcock (1) |
